DSS 2.0 PE
Annovi Reverberi Innovation Range: Dual Speed System
Dual Speed System:
DSS Series 2.0 PE
Pressure: 160 Bar
Flow Rate: 460 l/hr
160 Bar High-Pressure Washer for medium dirt uses with a dual speed system to reduce water and power consumption. Dual Speed System – Reduce electricity and water consumption by 30%.
High Pressure Washer designed to meet regular medium use needs at home, garden & trade uses. Innovative with the dual speed system, it is ideal for washing cars, vans, trucks, boats, pool, walls, stairs, paving, working tols, roofs, etc. Handy with wheels and a static hose reel, comes with a Total Stop System for safety and a built-in accessory storage.
DSS is the innovative technology system developed and produced by Annovi Reverberi equipped with DSS (Dual Speed System). Thanks to this technology, this high pressure washer with two speed motors and can provide different performances depending on requirements, by just turning the special POWER SWITCH.
In ECO SPEED mode, you can wash more delicate surfaces, such as wooden garden furniture, bicycles and outdoor textiles: in this mode, the high pressure washer will use the right power for these materials, combining effective washing with relatively low power and water use. In fact, ECO SPEED reduces water and energy consumption by 30%.
MAX SPEED mode, on the other hand, is better for applications that demand high cleaning force to remove stubborn dirt: it will use all the high pressure washer’s strength with standard energy consumption. MAX SPEED is specifically designed to work on stone, concrete or brick surfaces, or for effective cleaning of metal railings and gates, motor vehicles, and DIY and gardening tools.
30% Energy Saving,
Full Performance.
Gun holder
High pressure detergent tank
Rubber wheels for easy mobility
Static hose reel with super flexible hose 6m
3 Positions rotative switch off/ Eco Speed / Full Speed
Easy set-up with click-fast connection drive
DUEL SPEED SYSTEM – Reduce electricity and water consumption by 30%
Pressure Washer designed to meet regular medium use needs at home, garden & trade uses. Innovative with the dual speed system, it is ideal for washing cars, vans, trucks, boats, pool, walls, stairs, paving, working tools, roofs, etc. Handy with wheels and a static hose reel, comes with a Total Stop System for safety and a built-in accessory storage.
DSS is the innovative technology system developed and produced by Annovi Reverberi that enables the high pressure washer’s performances to be modulated to cleaning needs. With the handy 3-setting rotary switch, you can select the high pressure washer’s operating mode, with a choice between MAX SPEED and ECO SPEED. Effectively, this system provides a dual speed high pressure washer, which works with different performances depending on the job in hand and optimises energy consumption for the application.
MAX SPEED mode exploits the high pressure washer’s full power, and is recommended for the most aggressive, toughest conditions. ECO SPEED, on the other hand, lets you reduce water and energy use by 30% when less power is needed.
DSS Series 2.0 PE carry the Blue Clean Factor, the AR Blue Clean symbol awarded to the top products in any one category. This model is suited for operation with cold water and feature a series of very convenient, practical characteristics.
PRODUCT FEATURES
| SAFETY | Total Stop System with motor thermal protector |
| PUMP | – Dual Speed System – Reduce electricity and water consumption by 30% – 3 Axial stainless steel pistons wobble-plate pumps – Tempered stainless steel pistons – Automatic by-pass valve with pump head pressure discharge – Dual speed single-phase universal motor with thermal protector |
| STORAGE | Built-in accessory storage |
| DETERGENT TANK | Built-in detergent tank for direct suction |
| PORTABILITY | Two-wheel trolley with handle, hose reel, detergent tank and 3 position switch |
| WARRANTY | 2-year warranty for manufacturer defects |
| WATER TEMP | Use safely with water temperatures up to 122 ° F/50 ° |
| POWER SOURCE | Electric cable length 5m |
PRODUCT DATA
| MAX PRESSURE (bar) | 160 |
| MAX PRESSURE (psi) | 2300 |
| MAX FLOW RATE (l / h) | 460 |
| MAX FLOW RATE (gph) | 122 |
| POWER (Kw) | 2.2 |
| POWER SUPPLY (Hz) | 50-60 |
| POWER SUPPLY (V) | 220-240~ |
| UNIT DIMENSIONS (LxWxH) | 330x307x790 |
| WEIGHT(Kg) | 13,1 |
PRODUCT APPLICATIONS
Using the POWER SWITCH it is possible to select the ECO SPEED WASHING and MAX SPEED WASHING modes, to modulate the performance level of the pressure washer, adapting it to lighter cleaning needs, with a considerable saving of water and energy (up to 30%), or more intense depending on the work to be done.
ECO SPEED WASHING:
By activating ECO SPEED mode you can dedicate yourself to cleaning non-aggressive dirt on external wooden surfaces, bicycles, wooden garden furniture, external fabrics, with optimized energy consumption and a better compromise between washing / consumption effectiveness.
MAX SPEED WASHING:
By activating MAX SPEED mode you can dedicate yourself to cleaning aggressive dirt on stone, concrete and bricks, metal railings and gates, work and gardening tools, vehicles) with standard energy consumption.
PRODUCT APPLCATIONS
STANDARD ACCESSORIES
Trigger Gun
Code: 46328
Lance Extension (42cm)
Code: 46332
Adjustable Jet Nozzle
Code: 46327
Rotary Jet Nozzel
Code: 41565
Hose Pipe (6m)
Code: 46541
HIgh Pressure Foam Lance Bottle (400ml)
Code: 46572
Patio Cleaner
Code: 3085681
OPTIONAL ACCESSORIES
Multifunction Lance (48cm)
Code: 46352
Five in One Nozzle
Code: 46341
Extension HP Hose (8m)
Code: 46336
Water Filter Kit
Code: 41593
Click Fast Kit
Code: 41580
Adaptors Kit
Code: 41758
Adapters Kit
Code: 41890
Adjustable Head Nozzle Adaptor
Code: 46009
Extension Lance Kit (1,6m)
Code: 46355
Fixed Brush
Code: 46353
Fixed Brush
Code: 41577
Rotary Brush
Code: 41578
Power Brush
Code: 46361
Patio Cleaner
Code: 46356
Aquasweeper
Code: 46686
Water Suction Kit
Code: 41592
Pipe Drain Kit (10m)
Code: 41588
Pipe Drain Kit (16m)
Code: 41693
Sandblasting Lance Kit (50cm)
Code: 41760
Calibrated, Filtered Sand (5kg)
Code: 3207
Calibrated, Filtered Sand (25kg)
Code: 41770
WARRANTY CARD
AR Blue Clean offers a unique 2-year Home & Garden use warranty on Home and Garden range of Pressure Washers against defects due to faulty material and/or workmanship. If the product becomes defective within the warranty period, AR Blue Clean together with partners in various territories will repair, or at AR Blue Cleans discretion, replace free of charge.
All repair claims must be made through a AR Blue Clean authorized service centre and should be supported by the warranty registration card & purchase receipt.
